Ubiquiti UniFi Gateway Lite, Compact And Powerful UniFi Gateway, Advanced Routing And Security Features, USB-C Powered, 2Yr Warr

DESCRIPTION

Gateway Lite

Compact independent gateway with a full suite of advanced routing and security features.

Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues)

Managed by a CloudKey, Official UniFi Hosting, or UniFi Network Server with UniFi Network 8.0.7 and later

(1) GbE WAN port

(1) GbE LAN port

Compact footprint

USB-C powered (adapter included)

Advanced Security Features

Protect your network with application-aware firewall rules and signature-based IPS/IDS threat detection. These advanced capabilities provide next-generation security.

Energy-Efficient Operation

Powered via a USB-C adapter, the Gateway Lite combines functionality with energy efficiency.

Deployment

Build Features

The Ubiquiti Gateway Lite offers a sleek and minimal form factor, ideal for modern spaces. Its small size ensures it fits seamlessly into home or office environments.

Mechanical

Dimensions

98 x 98 x 30 mm (3.9 x 3.9 x 1.2")

Weight

320 g (11.3 oz)

Enclosure material

Polycarbonate

Hardware

Processor

Dual-core ARM® Cortex®-A53 at 1 GHz

Memory information

1 GB DDR3L

Management interface

Ethernet
Bluetooth 5.1

Networking interface

LAN: (1) GbE RJ45 port
WAN: (1) GbE RJ45 port

IDS/IPS throughput

1 Gbps*

*Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation.

Power method

USB type C (5V/3A)

Supported voltage range

100–240V

Max. power consumption

3.83W

Ambient operating temperature

-10 to 40° C (14 to 104° F)

Ambient operating humidity

5 to 95% noncondensing

Certifications

CE, FCC, IC

Gateway Features

Performance

WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Internet quality and outage reporting

Next-generation security

Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced networking

License-free SD-WAN*
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport* and Identity Enterprise VPN**
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IPv6 ISP support

*When paired with a CloudKey or Official UniFi Hosting.
**When paired with a CloudKey.

Application Requirements

UniFi Network

Version 8.0.7 and later

Ubiquiti Gateway Lite

SKU:UXG-Lite

Description:
A compact and powerful UniFi gateway with a full suite of advanced routing and security features

Tech Specs: Click Here
Installation Guide: Click Here

Features:
•Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues)
•Managed with a Cloud Key, Official UniFi Hosting, or UniFi Network Server
•(1) GbE WAN port
•(1) GbE LAN port
•Compact footprint
•USB-C powered
